RK3568 Android 4K 4GB 16GB Dual HD Monitor RS232 LCD Advertising Displayer Media Box

Brand Name : ADW

Model Number : AD-0146

Certification : CE ROHS FCC ISO9001 ISO 14001

Place of Origin : China

MOQ : 1 Set

Price : Negotiable

Payment Terms : T/T, Western Union, PayPal

Supply Ability : 30,000PCS

Delivery Time : Samples: 1-3 days; MP::15-30 days;

Packaging Details : Bubble bag

CPU solution : RK3568

OS : ANDROID 11

DDR/EMMC : 2GB RAM/16GB ROM

Display interface : LVDS/EDP/MIPI/HD OUT for display

Interface : USB X4, RS232, HD MI X2, LAN, Audio

Ethernet : 10/100/1000M Ethernet

Function : WIFI, BT, Wlan, Audio, speaker,etc.

RAM : 2GB/4GB/8GB/16GB Optional

Charger Type : US/UK/EU /AU optional

Wifi Support : Yes

Accessories : Power Adpater, Antenna

Rom : 16GB/32GB/32GB/64GB optional

Connectivity : USB, Wi-Fi, Ethernet

Mcu : For Low Power Control

Housing Color : Black or customized

Contact Now

RK3568 Android Media Player Box

RK3568 Android 4K 4GB 16GB Dual HD Monitor RS232 LCD Advertising Displayer Media Box

Overview:

The intelligent industrial all-in-one machine adopts the Rockchip RK3568 quad-core chip solution. Support Android 11 system. Enhanced power management circuit. Support commonly used external devices. Rich interfaces and stable performance. Suitable for intelligent remote network control: equipment such as industrial, medical, large advertising machines, educational video terminals and other equipment.

Features:

 High performance: The RK3288 chip uses the quad-core A17 solution and is one of the most powerful quad-core chips on the market. Compared with the common single-core, dual-core and quad-core solutions in the market, it has a qualitative leap in performance, can play high-definition video in various formats, and can process the complex interactive operations.

 High stability: RK3288 Android integrated board, add their own unique technology in the hardware&software to ensure the stability of the product. To make sure the device 7*24 hours unattended.

 High integration: RK3288 Android integrated board integrates Ethernet, wifi, Bluetooth, 4G, power amplifier, SD card, backlight power supply and other functions, greatly simplifying the design of the device. The ultra-thin motherboard makes the design of the device more beautiful.

 Multi interfaces: 6*USB ports, 3*UART ports, can connect more peripheral devices.

Products Description

RK3568 Android 4K 4GB 16GB Dual HD Monitor RS232 LCD Advertising Displayer Media Box

The large board of the intelligent industrial all-in-one machine adopts the Rockchip RK3568 quad-core chip solution. Support Android 11 system. Enhanced power management circuit. Support commonly used external devices. Rich interfaces and stable
performance. Suitable for intelligent remote network control: equipment such as industrial, medical, large advertising machines, educational video terminals and other equipment.

Product Parameter

System	CPU&GPU	Rockchip RK3568 quad-core 64-bit Cortex-A55, GPU Mali-G52
	RAM	2GB/4G (optional)
	Internal Storage	8GB/16GB/32GB/64GB(optional)
	OS	Android 11
Network	WiFi	IEEE 802.11b/g/n(optional)
	Ethernet	Support 10/100/1000M Ethernet
	Mobile Network	Support wireless 4G network(optional)
	Bluetooth	Bluetooth5.2
Interface	RS232	RS232 com port, male head DB9*1
	USB 2.0	USB 2.0_A*2
	HDMI_OUT_2	HDMI-A output supporting 1920*1080 60HZ
	DC holder*1	DC_12V input 5.5*2.1mm plug
	Headphone	3.5mm stereo headphone output
	USB_OTG	USB_A*1
	USB 3.0	USB 3.0_A*1
	HDMI_OUT_1	HDMI-A 2.0 output(supporting 3840*2160 60HZ)
	SIM card	SIM card slot*1(optional)
	Extended memory port	TF card slot*1
Button	Button	Upgrade button*1
Environmental Conditions	Working Environment	Temperature:-20~60℃,5%-85%RH (No condensation)
Environmental Conditions	Storage environment	Temperature:-20~70℃,5%-95%RH (No condensation)
Material	Adapter	Metal
Size	Product Size	Shell size:190.698.934.7mm

About Sunchip

RK3568 Android 4K 4GB 16GB Dual HD Monitor RS232 LCD Advertising Displayer Media Box

Established in 2012, Shenzhen Sunchip Technology Co., Ltd. is a comprehensive enterprise integrating design, research, development and production in digital consumer electronics products and solution provider. Our factory is located in Baoan district, Shenzhen city, near with Baoan International airport, which has more than 3200 square meters of standardized office base. Our company has been committed to the R and D and innovation in the field of digital electronics, complete and scientific quality management system and professional R&D team, strong product research and development, production capacity and perfect service system, make the company always keep the lead in the related fields. We regards quality as life and already passed ISO international quality system certification ISO9001/ MFi / CE / RoHs / FCC.From raw materials procurement, product production, testing, packaging, marketing and so on each link are carried out in strict accordance with the national standard quality. Sunchip has a over 80 research and development engineers team,high efficiency sales team and competitive price superiority, and attract customers from all over the world, we export to over 40 countries, including USA, UK, Germany, Italy, Japan,Korea, Turkey, Russia, Mexico, Brazil, Thailand ,Middle east and South Africa. Our sales team attends major exhibitions every year to close the distance with customers. Based on the principle of customer first, sales engineers have assisted customers to complete many projects, which are well received by customers. We are looking forward to cooperating, growing and developing with you sincerely.

Packing & Delivery

1.Packing: carton box or wood case

2.Payment methods: accept T/T,Western Union,Paypal and Cash.

3.RMA Policy: customer bear all the freight and duty charge to factory,and the factory afford return freight charge. 4.Warranty: 12 months warranty. Paid maintenance over 12 months.

5.Remark: ROHS, CE & FCC certificates in e-file format are available.

6.MOQ: 1pc, sample order are welcome for your evaluation.

RK3568 Android 4K 4GB 16GB Dual HD Monitor RS232 LCD Advertising Displayer Media Box

FAQ

1) Q: Is SUNCHIP a factory or simply a trading company?

A: We are a TRUE OEM/ODM factory. Please read our COMPANY PROFILE, for more information on this issue.

2) Q: What payment methods are available to me?

A: We accept most of the payment methods: accept VISA, Pay Later,T/T,Western Union,Paypal and Cash.

3) Q: How long is the warranty time?

A: 1 Year.

4) Q: What are the shipment terms and delivery times of your company?

A: Delivery / production time is directly affected by the size of the order. Also depending in which season you are shipping.

5) Q: Do you give any discounts ? A: Prices are directly affected by the quantity. We have many ways to help our partners when starting the sample processes. Make sure to ask our sales on how we can make you save some charges.

6) Q: I would like to add my company logo on your products, is this possible?

A: SURE.We customize on a regular basis products for many large retaillers and brands. If your order is at the below 10 units, we can consider this as a SAMPLE order, some fees might apply for the logo prints.Different methodes are used for logos, please ask our sales for more information on this issue, we will surely find the right solution for you!
