Overview:
Intelligent industrial all in one board, using Rockchip RK3399 six-core chip program, support Google Android7.1 or higher system. Powerful computing power. Support H.265 4K video playback. Rich interface and enhanced power management circuit. Suitable for intelligent remote network control: industrial, medical, large advertising, educational video terminals and other equipment.
Characteristic:
- Supporting LVDS interface display
- Supporting EDP interface display
- Supporting MIPI interface display
- Various interactive mode interfaces: capacitive touch, infrared touch, infrared remote control, USB keyboard and mouse, multi-point optical touch.
- Various network interfaces: Ethernet, wireless Wifi, Bluetooth.
- Multi-channel USB interface and serial port Output
- Support 4K video playback and HDMI 2.0 HD Output.
- Strong anti-electromagnetic interference and electromagnetic compatibility.
Basic hardware specifications:
| CPU | Rockchip RK3399 hexa-core
Dual-core Cortex-A72 up to 1.8GHz Quad-core Cortex-A53 up to 1.4GHz |
| GPU | ARM Mali-T860MP4 GPU Support AFBC (Frame Buffer Compression) |
| RAM | LPDDR4 2G/4Goptional |
| ROM | EMMC 16G/32G/64G optional |
| Display interface | LVDS interface (MIPI and LVDS , pick one of two) |
| MIPI interface (MIPI and LVDS, pick one of two) |
| EDP interface |
| LVDS screen voltage | Support 3.3V/5V/12V optional. |
| Network | Equip with RJ45 interface , supporting 10/100M Ethernet. |
| Equip with Wifi & BT module, 2.4GHz/5G, supporting wifi6
support Wi-Fi 802.11a/b/g/n/ ac/axprotocol support BT 5.3 |
| Image rotation | Support manual rotation of 0, 90, 180 and 270 degrees, and support gravity sensing function. |
| Real-time clock | External real-time clock power supply battery |
| Interface equipment | Support MIPI camera |
| 2x USB3.0,including 1x USB OTG |
| 4x USB HOST (support USB camera @500W USB printer, USB drive, mouse and keyboard standard USB peripherals) |
| 2x UART (optional TTL/RS232), supporting external serial devices (NFC module, printer, card reader, etc.), 1x SPI. |
| TF card, support 64GB max. |
| Class D power amplifier: 5W *2 8Ω, supporting microphone. |
| HDMI 2.0 Output |
| Audio frequency | MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP format |
| Video | Support H.264, MPEG-2, VP6, VP8, MVC and other video formats for 2160P@24FPS decoding, YouTube and other online videos, up to 4K, HTML5 video playback and Flash10.1 playback. |
| Image | Support various image formats such as JPG, BMP, PNG, GIF, etc., and support rotation/image enlargement function. |
| Power adapter | Input:AC100-240V, 50-60HZ Output:DC12V 3A |
Basic software specification:
| Operating System | Android 7.0 and above |
| Basic software functions | Web browsing, e-mail, e-books, resource management |
| Sound effect mode | Clock, alarm clock, calculator |
| Voice support | Multilingual language |
| Record | Support MP3 and WMA format recording. |
| Tool | Calendar |
| Alarm Clock |
| Calculator |
| Note |
| Weather+clock |
| Record |
| Document handling | EPUB, WORD, EXCEL, POWERPOINT, PDF, TXT |
| Electronic book | PDF/TXT/CHM/DOC/EXCEL/EPUB/RTF/FB2 |
| Schedule | Calendar |
| Input | Standard android keyboard, optional third-party Input method (Chinese, Korean, Japanese, etc.) |
| Systems management | APK installer |
| Original ecological Android system, open root permissions, can be customized for product development. |
| Support OTA remote upgrade |
| System setting |
| Global time |
